Carousel (ALPHA)

BusinessEnterprise
Alpha feature: invite only

Responsive Widgets are in alpha and available by invitation only on Business and Enterprise plans. Behavior and properties may change. To request access, open a support ticket and name the feature Responsive Widgets (ALPHA).

The Carousel widget shows a list of images with optional captions. In Carousel appearance, it shows one slide at a time with arrows, dots, and optional auto-advance. In Gallery appearance, it shows all images at once in a grid. Use it for product photos, banners, or image results from a query.

Widget type: WDS_CAROUSEL_WIDGET

Carousel widget in a Responsive app
Carousel widget

Which image URLs work​

The widget checks each slide's image URL before it loads it. It allows:

  • URLs on the same origin as your app, including relative paths.
  • Absolute https: URLs on any domain.

It rejects http: URLs on another domain, SVG data URLs, javascript:, blob:, other schemes, and protocol-relative values such as //example.com/a.png. A slide with a rejected or empty image shows an empty placeholder. Screen readers still read its alt text.

Images load with referrerPolicy="no-referrer", so the image host does not see your app's URL.

Content properties​

These properties appear in the Content tab of the property pane.

Data​

Slides array​

Sets the slides. Each slide is an object with these keys:

  • image string: the image URL. See Which image URLs work.
  • altText string, optional: text that screen readers read for the image.
  • caption string, optional: text shown under the image.

The widget uses the first 50 slides and ignores the rest. It skips entries that are not objects. New widgets start with two sample slides.

While a bound query loads and there are no slides yet, the widget shows a loading skeleton. If the array is empty, the widget shows "No slides to display."

Example:

{{GetPhotos.data.map(p => ({ image: p.url, altText: p.title, caption: p.title }))}}

Default slide number​

Sets the slide shown first, counting from 0. Default: 0. Values out of range are moved to the nearest valid slide. Hidden when Appearance is Gallery.

General​

Show arrows boolean​

Shows the previous and next arrows. Default: on. Arrows only show when there is more than one slide. Hidden when Appearance is Gallery.

Show dots boolean​

Shows a dot for each slide. Users can click a dot to go to that slide. Default: on. Dots only show when there is more than one slide. Hidden when Appearance is Gallery.

Loop boolean​

Goes from the last slide back to the first, and from the first to the last. Default: on. Hidden when Appearance is Gallery.

Height (px) number​

Sets the height of the slide area in pixels. The minimum is 40. Default: 320. Hidden when Appearance is Gallery.

Visible boolean​

Controls whether the widget is visible. Default: on.

Animate loading boolean​

Controls the loading animation of the widget. Default: on.

Auto-advance​

Auto-advance boolean​

Moves to the next slide on a timer. Default: off. You cannot bind this property. Hidden when Appearance is Gallery.

Auto-advance pauses while the pointer is over the widget or the widget has focus. It is off when the user's operating system has "reduce motion" turned on. It also does nothing when there is only one slide.

Interval (ms) number​

Sets the time between slides, in milliseconds. The value must be from 2000 to 30000. Default: 5000. Shows when Auto-advance is on and Appearance is Carousel.

Events​

See Events.

Style properties​

These properties appear in the Style tab of the property pane.

General​

Appearance string​

Sets how the widget shows slides. You cannot bind this property. Options:

  • Carousel (default): one slide at a time, with navigation.
  • Gallery: all slides as a static image grid. Navigation, auto-advance, and the onSlideChange event do not apply.

Visual separation boolean​

Adds the theme's elevated background and border around the widget. This sets it apart from the rest of the page. Default: off.

Keyboard and screen readers​

In Carousel appearance:

  • When the widget has focus, the Left and Right arrow keys move between slides.
  • Screen readers announce the active slide, for example "Slide 2 of 5."
  • When the user's system has "reduce motion" on, slides change without a scroll animation.

Reference properties​

Reference properties let you read the widget's state in bindings and code, for example {{Carousel1.isVisible}}. You cannot set them directly.

isVisible boolean​

Shows whether the widget is visible.

Example:

{{Carousel1.isVisible}}

slides array​

Holds the slides array.

Example:

{{Carousel1.slides.length}}

activeSlide number​

Holds the index of the slide on screen, counting from 0.

Example:

{{Carousel1.slides[Carousel1.activeSlide].caption}}

Methods​

Methods let you change the widget's properties from code, for example in a JS Object.

setVisibility (param: boolean): Promise​

Shows or hides the widget.

Example:

Carousel1.setVisibility(false)

setActiveSlide (param: number): Promise​

Goes to a slide by its index, counting from 0. This method sets Default slide.

Example:

Carousel1.setActiveSlide(2)

Events​

onSlideChange​

Runs when the active slide changes. This happens when users click an arrow or a dot, press an arrow key, or when auto-advance moves the slide. Read the new index in activeSlide. Hidden when Appearance is Gallery.
