Embed (ALPHA)

BusinessEnterprise

Alpha feature: invite only

Responsive Widgets are in alpha and available by invitation only on Business and Enterprise plans. Behavior and properties may change. To request access, open a support ticket and name the feature Responsive Widgets (ALPHA).

The Embed widget shows other content inside your app, in a frame. It has three modes: a web page from a URL, your own HTML, or a document such as a PDF or a Word file. It replaces the Iframe and Document Viewer widgets of fixed-layout apps.

Widget type: WDS_EMBED_WIDGET

Embed widget

Security rules

The widget applies these rules in every app. You cannot turn them off.

URL checks

The widget checks the URL in URL mode and in Document mode. It allows:

• URLs on the same origin as your app, including relative paths.
• Absolute https: URLs.

It rejects:

• http: URLs on another domain.
• All data: URLs.
• javascript:, blob:, file:, and other schemes.
• Protocol-relative values, such as //example.com.

When the URL is empty or rejected, the widget does not load a frame. It shows a message instead:

• URL mode: "Provide a same-origin or https URL to embed."
• Document mode: "No document URL provided," or "Only same-origin or absolute https document URLs render."
• Inline HTML mode with no HTML: "Add HTML to render."

The frame always loads with referrerPolicy="no-referrer", so the embedded site does not see your app's URL.

Sandbox

The frame always has a sandbox attribute:

Mode	Sandbox allows
URL	allow-scripts allow-forms allow-popups
Document	allow-scripts allow-forms allow-popups
Inline HTML	allow-forms allow-popups (no scripts)

The sandbox never allows allow-same-origin, allow-top-navigation, allow-top-navigation-by-user-activation, or allow-popups-to-escape-sandbox. This means:

• Embedded scripts run in a separate, unique origin. They cannot read your app's cookies, storage, or page.
• The embedded page cannot redirect the user's browser tab.
• Popups the embedded page opens stay sandboxed.

Unlike the fixed-layout Iframe widget, this widget has no setting to turn off the sandbox.

Browser permissions

By default, the frame cannot use the camera, microphone, location, screen capture, or payments. You can grant each one in the Permissions section. A granted permission applies only to the embedded URL's origin.

Messages from the embedded page

The onMessageReceived event runs only when both of these are true:

• The message comes from the same origin as the embedded URL.
• The message comes from this widget's own frame, not another window.

Before the widget stores the message, it copies it as JSON. This drops functions and other values that JSON cannot hold. It also removes __proto__, constructor, and prototype keys. Messages that cannot be copied become undefined.

Content properties

These properties appear in the Content tab of the property pane. This widget has no Style properties.

Data

Mode string

Sets what to embed. You cannot bind this property. Options:

• URL (default): a web page.
• Inline HTML: HTML you write or bind.
• Document: a document file.

URL string

Sets the page to embed. Shows when Mode is URL. See URL checks. Default: https://www.example.com.

HTML string

Sets the HTML to show. Shows when Mode is Inline HTML. Scripts do not run in this mode.

Example:

<p>Inline HTML</p>

Document link string

Sets the URL of a document, such as pdf, txt, docx, xlsx, or pptx. Shows when Mode is Document. See URL checks.

• Files that end in .doc, .docx, .ppt, .pptx, .xls, or .xlsx open in the Microsoft Office Online viewer at https://view.officeapps.live.com. The widget sends the document URL to that viewer. The document must be reachable from the internet for the viewer to show it. Do not use signed or secret links for confidential documents.
• Other files, such as PDF and text files, load directly in the frame.

Title string

Sets the frame's accessible name for screen readers. If empty, the frame uses "Embedded content."

Permissions

This section is hidden when Mode is Inline HTML. All permissions are off by default.

Allow camera boolean

Lets the embedded page use the camera.

Allow microphone boolean

Lets the embedded page use the microphone.

Allow location boolean

Lets the embedded page read the user's location.

Allow screen capture boolean

Lets the embedded page capture the screen.

Allow payment boolean

Lets the embedded page use the Payment Request API.

General

Visible boolean

Controls whether the widget is visible. Default: on.

Animate loading boolean

Controls the loading animation of the widget. Default: on.

Events

See Events.

Reference properties

Reference properties let you read the widget's state in bindings and code, for example {{Embed1.isVisible}}. You cannot set them directly.

isVisible boolean

Shows whether the widget is visible.

Example:

{{Embed1.isVisible}}

source string

Holds the URL set in URL mode.

Example:

{{Embed1.source}}

srcDoc string

Holds the HTML set in Inline HTML mode.

Example:

{{Embed1.srcDoc}}

docUrl string

Holds the document link set in Document mode.

Example:

{{Embed1.docUrl}}

title string

Holds the frame title.

Example:

{{Embed1.title}}

message any

Holds the last message the embedded page sent, after the checks in Messages from the embedded page. It is empty until the first message arrives.

Example:

{{Embed1.message}}

Methods

Methods let you change the widget's properties from code, for example in a JS Object.

setVisibility (param: boolean): Promise

Shows or hides the widget.

Example:

Embed1.setVisibility(false)

setURL (param: string): Promise

Sets the URL for URL mode. The same URL checks apply.

Example:

Embed1.setURL("https://docs.appsmith.com")

setSrcDoc (param: string): Promise

Sets the HTML for Inline HTML mode.

Example:

Embed1.setSrcDoc("<h1>Hello</h1>")

setDocumentURL (param: string): Promise

Sets the document link for Document mode. The same URL checks apply.

Example:

Embed1.setDocumentURL("https://example.com/report.pdf")

Events

onURLChanged

Runs when the URL property changes, for example through a binding or setURL(). It does not run on first load. It does not run when users click links inside the embedded page. Shows when Mode is URL.

onMessageReceived

Runs when the embedded page sends a message with postMessage, and the message passes the checks in Messages from the embedded page. Read the message in {{Embed1.message}}. Hidden when Mode is Inline HTML, because inline HTML cannot send messages that pass the checks.
