Image (ALPHA)

BusinessEnterprise
Alpha feature: invite only

Responsive Widgets are in alpha and available by invitation only on Business and Enterprise plans. Behavior and properties may change. To request access, open a support ticket and name the feature Responsive Widgets (ALPHA).

The Image widget shows an image from a URL. Use it for logos, banners, product photos, or images from a query. You can set a fallback image for when the main image does not load.

Widget type: WDS_IMAGE_WIDGET

Image widget in a Responsive app
Image widget

Which image URLs work​

The widget checks every image URL before it loads it. This applies to Image and Fallback image. It allows:

  • URLs on the same origin as your app, including relative paths such as /assets/logo.png.
  • Absolute https: URLs on any domain.

It rejects:

  • http: URLs on another domain.
  • javascript:, blob:, file:, and other schemes.
  • Protocol-relative values, such as //example.com/a.png.

The widget loads images with referrerPolicy="no-referrer", so the image host does not see your app's URL.

The widget tries the images in this order:

  1. Image, if it passes the check and loads.
  2. Fallback image, if Image is empty, rejected, or fails to load.
  3. An empty state that shows the Alt text, or "No image" if alt text is empty.

Content properties​

These properties appear in the Content tab of the property pane.

Data​

Image string​

Sets the URL of the image. See Which image URLs work. Default: https://assets.appsmith.com/widgets/default.png.

While a bound query loads and no image is set yet, the widget shows a loading skeleton. When a query runs again, the widget keeps the current image until the new one arrives.

Example:

{{Products.selectedRow.photo_url}}

Alt text string​

Sets the text that screen readers read for the image. The empty state also shows this text. This field is required. Default: Image.

Fallback image string​

Sets an image to show when the main image is empty, rejected, or fails to load. The same URL checks apply.

General​

Object fit string​

Sets how the image fills its box. Options:

  • Cover (default): fills the box and crops the image if needed.
  • Contain: shows the whole image inside the box.
  • Fill: stretches the image to fill the box.
  • Scale down: like Contain, but never makes the image larger than its real size.

Values for code: cover, contain, fill, scale-down.

Visible boolean​

Controls whether the widget is visible. Default: on.

Animate loading boolean​

Controls the loading animation of the widget. Default: on.

Events​

See Events.

Style properties​

These properties appear in the Style tab of the property pane.

General​

Visual separation boolean​

Adds the theme's elevated background and border around the image. This sets it apart from the rest of the page. Default: off.

Reference properties​

Reference properties let you read the widget's state in bindings and code, for example {{Image1.isVisible}}. You cannot set them directly.

isVisible boolean​

Shows whether the widget is visible.

Example:

{{Image1.isVisible}}

image string​

Holds the image URL, as you set it.

Example:

{{Image1.image}}

altText string​

Holds the alt text.

Example:

{{Image1.altText}}

fallbackImage string​

Holds the fallback image URL.

Example:

{{Image1.fallbackImage}}

Methods​

Methods let you change the widget's properties from code, for example in a JS Object.

setVisibility (param: boolean): Promise​

Shows or hides the widget.

Example:

Image1.setVisibility(false)

setImage (param: string): Promise​

Sets the image URL. The same URL checks apply.

Example:

Image1.setImage("https://example.com/photo.png")

Events​

onClick​

Runs when users click the image. When you set this event, the image becomes a button. Users can also reach it with the keyboard and press it.
