Card (ALPHA)

BusinessEnterprise

Alpha feature: invite only

Responsive Widgets are in alpha and available by invitation only on Business and Enterprise plans. Behavior and properties may change. To request access, open a support ticket and name the feature Responsive Widgets (ALPHA).

The Card widget is a container. You drop other widgets into its body. It can also show an image at the top, a header row with an avatar, title, and subtitle, and a footer with up to two action buttons. Use it to group content about one item, such as a customer, product, or task.

A new Card starts with every extra part turned off. It is just a surface with an empty body. Turn on the parts you need in the property pane.

Widget type: WDS_CARD_WIDGET

Card widget

Card layout

From top to bottom, a card shows:

1. Media header: an image band. Shows when Show media header is on.
2. Header row: avatar, title, and subtitle. Shows when Show header is on.
3. Body: the widgets you drop into the card.
4. Footer: the secondary and primary action buttons. Shows when Show footer is on and at least one action has a label.

If you delete the card's body from the entity explorer, the editor shows "This card's body was deleted. Undo to restore it." Use undo to bring it back.

Image URLs

The media image and the avatar image use the same URL checks as the Image widget. They allow:

• URLs on the same origin as your app, including relative paths.
• Absolute https: URLs on any domain.

They reject http: URLs on another domain, SVG and other data URLs, javascript:, blob:, other schemes, and protocol-relative values such as //example.com/a.png. Images load with referrerPolicy="no-referrer".

Content properties

These properties appear in the Content tab of the property pane.

Media

Show media header boolean

Shows an image band above the card content. Default: off.

Image string

Sets the URL of the media image. Shows when Show media header is on. See Image URLs. If the URL is empty, rejected, or fails to load, the band shows the Alt text, or "No image" if alt text is empty.

Alt text string

Sets the text that screen readers read for the media image. The empty band also shows this text. Shows when Show media header is on.

Header

Show header boolean

Shows the avatar, title, and subtitle row above the body. Default: off.

Title string

Sets the card title. Long titles are cut to one line. Shows when Show header is on. Default: Card title.

Subtitle string

Sets a line of supporting text under the title. Long text is cut to one line. Shows when Show header is on.

Show avatar boolean

Shows an avatar at the start of the header row. Shows when Show header is on. Default: off.

The avatar shows the image first. If there is no image, or the image is rejected or fails to load, it shows initials. If there is no label for initials, it shows an icon.

Avatar image string

Sets the URL of the avatar image. See Image URLs. Shows when Show header and Show avatar are on.

Avatar label string

Sets the avatar's accessible name and the source of its initials. If empty, the avatar uses the title. Shows when Show header and Show avatar are on.

Footer

Show footer boolean

Shows the footer action row below the body. Default: off.

Primary action label string

Sets the label of the primary button. This is a filled button that comes after the secondary button. Leave it empty to hide the button. Shows when Show footer is on. Default: Confirm.

Secondary action label string

Sets the label of the secondary button. This is an outlined button that comes before the primary button. Leave it empty to hide the button. Shows when Show footer is on.

General

Visible boolean

Controls whether the widget is visible. Default: on.

Loading boolean

Shows a skeleton over the card while on. The card content stays in place under the skeleton, so the widgets inside keep their state. While loading, clicking the card does nothing. Default: off.

The card also shows the skeleton on its own while a query it depends on is running.

Example:

{{Query1.isLoading}}

Animate loading boolean

Controls the loading animation of the widget. Default: on.

Events

See Events.

Style properties

These properties appear in the Style tab of the property pane.

General

Variant string

Sets the look of the card surface. Options:

• Elevated (default): a raised surface with a shadow.
• Filled: a tinted surface with no border or shadow.
• Outlined: a surface with a thin border.

Values for code: elevated, filled, outlined.

Reference properties

Reference properties let you read the widget's state in bindings and code, for example {{Card1.isVisible}}. You cannot set them directly.

isVisible boolean

Shows whether the widget is visible.

Example:

{{Card1.isVisible}}

title string

Holds the card title.

Example:

{{Card1.title}}

subtitle string

Holds the card subtitle.

Example:

{{Card1.subtitle}}

variant string

Holds the card variant: elevated, filled, or outlined.

Example:

{{Card1.variant}}

showSkeleton boolean

Shows whether the Loading setting is on.

Example:

{{Card1.showSkeleton}}

Methods

Methods let you change the widget's properties from code, for example in a JS Object.

setVisibility (param: boolean): Promise

Shows or hides the widget.

Example:

Card1.setVisibility(false)

setLoading (param: boolean): Promise

Shows or hides the loading skeleton. This method sets Loading.

Example:

Card1.setLoading(true)

Events

onClick

Runs when users click the card surface. Clicks on buttons, links, inputs, and other interactive widgets inside the card do not run it. Keyboard and screen reader users can trigger it with a hidden button at the start of the card. That button is named after the card title, or the widget name if the title is empty.

onPrimaryClick

Runs when users click the primary footer button. Shows when Show footer is on.

onSecondaryClick

Runs when users click the secondary footer button. Shows when Show footer is on.
